CPU
-Qualcomm Snapdragon
-octa-core
Adapter
-Input: AC100-240V/1.7A
-Output: 24V/2.5A
Port
-5× USB Type-A ports
-1× RJ11 Serial port
-1× RJ12 Cashbox port
-1× RJ45 LAN port
-1× Audio Jack port
-1× Power port
-1× Micro-USB debug port
Environment
Operating temperature:
-0°C ~ 40°C
Storage temperature:
-10°C ~ 50°C
Speaker
-3W
Button
-Power button
-(lock screen button)
-Volume up/down button
OS
-Android 7.1
-SUNMI OS
Memory
-2GB RAM + 16GB ROM
Touch Screen
-Capacitive
-multi-touch screen
Wi-Fi
-2.4G/5G
-Supports IEEE 8

-The 10.1 ” FHD screen adopts Corning Gorilla Glass, which is impact- & scratch-resistant.
-With a built-in 8360mAh battery, it can work for over 12 hours continuously, and the standby time can be up to 20 days.
-An ergonomic scanner inbuilt let you easily and quickly read 1D/2D barcodes, even if scratched, folded or stained.
OS
-SUNMI OS
(*based on Android 9.0)
Processor
-Kryo-260 octa-core,
-2.2GHz
Memory
Config 1:
-3GB RAM + 32GB ROM
Config 2:
-4GB RAM + 64GB ROM
Display
-10.1" FHD, 1920*1200
-Capacitive multi-touch
Camera
-Front: 5MP FF
-Rear: 13MP, Flash, AF
-1D/2D barcode reading
NFC Reader
T-ype A & B card,
-Mifare card, Felica card;
ISO/ICE 14443 and ISO15693
standards compliant
Speaker
-2* 1W
PSAM Card Slot
-1* PSAM
vSIM
-Supports vSIM (Config 2)
SIM Card Slot
-1* MicroSD (TF) (Config 1)
-2* NANO SIM OR 1* NANO SIM+1* MicroSD (TF) (Config 2)
Network
-2G & 3G & 4G
Wi-Fi
-2.4GHz/5GHz
-IEEE 802.11 a/b/g/n/ac
Bluetooth
-Bluetooth 5.0
BLE
GPS
AGPS
GPS/Glonass/Beidou
(Config 2)
Sensors
Gravity sensor, light sensor,
compass sensor,
hall sensor
Buttons
1* Power on/off button
(lock screen button)
2* Volume (+/-) button
MIC
2*MIC
Ports
1* Type-C, OTG supported
1* Audio jack,
supports POGO Pin
Battery
Nonremovable LiPo battery
3.85V/8360mAh
Power Adapter
-Input: AC 100~240V
-Output: DC 5V/2A
Dimensions (L*W*H)
-245.6*164.4*9.9mm (thinnest)
Total Weight
Standard Version:
-673g
Scanner Version:
-735g
Protection Ratings
-IP65
-1.0m drop spec
Environment
-Operating temp: -20°C~55°C
-Storage temp: -40°C～70°C
Accessories
-hand strap
-charging and extendable cradle (optional)
-protective case (optional)
Scanner
-Professional 2D scan engine
(*Only supported by scanner version)

Model Approved
Config 1: L1323 (80mm printer +WIFI)
Config 2: L1323 (80mm printer + NFC + Scanner+4G)
OS
Android OS
SUNMI OS
CPU
Cortex-A53
octa-core 1.4GHz
Memory
2GB RAM + 16GB ROM
Display
Capacitive multitouch
Main Display：
11.6" FHD 1920*1080
Secondary Display:
LED Display，FSTN ,128*40
Camera
0.3MP
Supports 1D/2D barcode recognition (Config 2)
Printer
Built-in 80mm thermal printer
Auto cutter: equipped
Print speed: 160mm/s
Service life: 100Km, Paper roll: Φ60mm
NFC Card Reader
Supports Type A&B card,
Mifare card, Felica card
ISO/ICE 14443 compliant
Scanner
Supports 1D/2D barcode recognition
(Config 2)
Speaker
1* 1.2W
SIM Card Slot
1* MINI SIM (Config 2)
Network
2G & 3G & 4G (Config 2)
Wi-Fi
2.4GHz
Supports IEEE 802.11 b/g/n
Bluetooth
Supports Bluetooth 2.1/3.0/4.2
Supports BLE
Wired Network
LAN 100M
Button
1* Power (lock screen) button
2* Volume (+/-) button
TF Card
1* MicroSD (TF)
Up to 64G
Ports
4* USB Type A port
1* RJ11 serial port
1* RJ12 cash drawer port
1* RJ45 LAN port
1* Audio jack
1* Power port
1* Micro USB debug port
Power Adapter
Input: AC100~240V/1.7A
Output: DC24V/2.5A
Dimensions (L*W*H)
294*303*107mm
Total Weight
2.0Kg
Environment
Operating temperature: 0°C~40°C
Storage temperature: -20°C~60°C

CPU
Quad-core
1.5GHz or 1.3GHz

OS
Android OS
Sunmi OS

Memory
1GB RAM+8GB ROM

Display
5.5" HD+
1440×720，IPS

Touch Screen
Capacitive multi-touch

Printer
High-speed thermal printer
Print speed: 70mm/s
Till roll width/diameter:
58mm/40mm

Communication Methods
LTE/UMTS/GSM

Wi-Fi
2.4G/5G, Supports IEEE
802.11 a/b/g/n

Bluetooth
Supports 2.1/3.0/4.0 BT

GPS
GPS, AGPS

Camera
Front camera: 0.3 Megapixel(Optional)
Rear camera: 5 Megapixel
Auto Focus Camera

Fingerprint
FAP10, FBI/STQC
(Optional)

Battery
li-polymer battery
7.6V/2540mAh

Interface
One USB-Type C
Support OTG

Adaptor
Input: AC100-240V, 0.3A
Output: 5V/2A

Charging Base
Supports charging
Supports USB OTG function

Dimensions
222*81.6*17.6mm

Total Weight
400g

Environment
Operating Temperature:
-10°C～50°C
Storage Temperature:
-20°C～60°C
